Description
Barksdale's Series III-L valve provides an optimal solution for the upmost reliability and safety by combining the dependable features of our heavy duty Shear-Seal® valves with the reliability of the integrated actuator, providing an all in one package saving customers time in installation and maintenance. With the ability to handle high pressure demands between 3000 to 5000 psi while maintaining a high flow capability of 75 GPM, the Series III-L is well suited to tolerate contaminated media. The combination of the high flow and high pressure and virtually zero-leakage* makes the Series III-L valve the choice for the toughest applications where zero-leakage* is a must.
Features
- Original Shear-Seal® technology
- 2 & 3 position valve
- 2 position actuated valve
- Manual override Air or hydraulic integrated actuator
- Superior shifting performance
- High flow with low pressure drop
- Rugged integrated solution
- Extended shaft for alternate position sensor
- Robust detent stop
- Panel mounting option
- Position indication option
- Suitable for hydraulic & water glycol media
Applications
- Land-based oil drilling controls
- BOP accumulator units
- Test systems
- Workover rigs
- Mobile drilling rigs
- Hydraulic based industrial applications
