Magnetic Pickup

M920 Series

CML 19ATEX2489X-M920 - ATEX Certification

Download

IECEx_CML-M920 - IECEx Certification

Download

Magnetic Pickup: intrinsically safe, power zener, extra long reach

Description

Multiple Thread Sizes and Lengths
Active (Powered) - Hazardous Area
Zero Speed Hall-Effect Sensors

This hall-effect sensor is ATEX and IECEx approved for use in hazardous areas: Ex mb (Zone 1, 2) and Ex ia (Zone 0, 1, 2). It is designed to sense ferrous material (gear teeth, hole, pin, etc.) for speed measurement down to zero-speed. The sensor outputs are TTL and Vin-based and are compatible with most PLC input cards. M920 has multiple thread sizes of UNF2A and M (metric) type, and thread lengths from 1.875” to 6”.

The 300 series stainless steel housing is fully potted with hazardous area rated epoxy resin with no air gap inside, which makes it a reliable, robust and absolutely safe for use in hazardous areas.

Request Quote

Frequently Asked Questions

Find answers to common questions below

A1: A Magnetic Pickup Passive (Variable Reluctance) Speed Sensor is a device used to measure the speed of a rotating object by detecting changes in magnetic fields. It is part of the Dynalco brand products offered by Barksdale.
A2: Under the Dynalco brand, there are several types of magnetic pickups available, including Active Pickups, Passive Pickups, and Hall Effect Pickups. These are categorized for both hazardous and non-hazardous areas.
A3: Barksdale offers a variety of product categories including Flow (Valves, Regulators, Flow Switches), Level (Transmitters, Indicators, Float Switches), Pressure (Switches, Transducers), Temperature (Thermostats, Switches), and Speed-related products under the Dynalco brand.
A4: More information about Barksdale's products can be found on their website under the 'Products' section, which includes detailed categories for Flow, Level, Pressure, Temperature, Speed, and Air Suspension Valves.
A5: Industries that require precise speed measurement for rotating machinery, such as manufacturing, automotive, and aerospace sectors, might be interested in using Barksdale's Magnetic Pickup Speed Sensors.
